WSC — Generic Training Simulators

Baseline plant knowledge at a fraction of the cost

Not every training problem requires a customized solution. WSC's generic simulator solutions provide operators and students with the baseline knowledge and familiarity essential to safely and efficiently manage a power plant — based on real operating units, completely tested and verified.

Platform & Deployment

Flexible Access — Anywhere in the World

Generic Training Simulators allow students to perform complete plant startups, shutdowns, and load maneuvers — and realistically replicate normal and abnormal plant transients including malfunction scenarios. They can be integrated with 3KEYSTUDENT™ and a Learning Management System (LMS) to track each student's progress through lessons.

Deployment options:

🖥️

Client / Server (LAN)

Installed at customer site using standard local area network technologies.

💻

Standalone

Models and HMI run on the same computer — no network infrastructure required.

🏫

Classroom

Multi-seat classroom environments with 3KEYCLASS instructor management.

🌐

Web-based

Access via Internet from anywhere in the world through a web-based simulator interface.

Target audience:

Newly formed regulatory agencies Universities Technical institutes Power plant operators Engineering students Company personnel

Check how close our simulators are to your plant. Complete a short configurator questionnaire — WSC offers a great range of generic Combined Cycle, Simple Cycle, and Fossil simulators.

Start Configurator →

Generic Nuclear Simulator

Pressurized Light Water Reactor — GPWR

Thermal power

3,983 MW

Electric power

1,400 MW

Turbine speed

3,000 rpm

Loops / SGs / Pumps

2 / 2 / 4

A Pressurized Light Water Reactor with two circulation loops, two vertical steam generators, and four reactor coolant transfer pumps. Steam generators supply steam to a turbine consisting of one high-pressure and three low-pressure cylinders. Condensate is pumped from three condensers through low-pressure heaters to two turbine-driven feedwater pumps, which supply feed flow through high-pressure heaters to the steam generators. Four moisture separator reheaters separate and reheat high-pressure turbine exhaust steam for the low-pressure turbines.

Over 75 graphic control screens — cold shutdown to full power operation

10,000 supervised points with alarm and event system for fault analysis

Full-featured trending system for supervision of single or multiple parameters

Full-featured Instructor Station capable of inserting hundreds of malfunctions

Generic VVER Simulator

VVER Gen III+ Nuclear Power Plant — GVVER

Thermal power

~3,200 MW

Electric power

~1,200 MW

Turbine speed

3,000 rpm

Loops / SGs / Pumps

4 / 4 / 4

A Pressurized Light Water Reactor with four circulation loops, four horizontal steam generators, and four reactor coolant transfer pumps. Steam generators supply steam to a turbine consisting of one high-pressure and four low-pressure cylinders. Condensate is pumped from four condensers through low-pressure heaters to a deaerator and to five feedwater electric pumps, which supply feed flow through high-pressure heaters to the steam generators. Four moisture separator reheaters separate and reheat high-pressure turbine exhaust steam for the low-pressure turbines.

Over 140 graphic control screens — cold shutdown to full power and all transients

Includes Fukushima safety systems — post-Fukushima design features fully modeled

Full-featured trending system for supervision of single or multiple parameters

Full-featured Instructor Station capable of inserting hundreds of malfunctions

Find Your Simulator

Ready to get started with a generic simulation solution

Generic training simulators provide baseline plant knowledge at a fraction of the cost of a custom simulator — based on real, tested, and verified operating units. Use the configurator to find your best match, or contact WSC directly.

Start Configurator → Contact WSC →
